Operating with Programmers
99
Now you should press the button on the programmer to which you would like to assign the site #1. Then
the ChipProgUSB will prompt to assign the site #2 to another programmer (in case there are more than
two programmers in the programming cluster), etc. After assigning numbers to the programmers you will
get the Program Manager window that differs from the same window that you get when you work with
one programmer.
5.5.1
5.5.1.1
The Program Manager Window
The Program Manager window is the major control object on the screen from which an operator
controls the ChipProg . While some windows can be closed in a process of programming this one is
supposed to be always open and visible. The window appearance differs from the same Program
Manager window that you get when you work with one programmer.
The window includes three tabs, opening three groups of settings and status indicators:
The Project Manager tab
The Options tab
The Statistics
Project Manager and Options tabs look differently and enable different settings for the ChipProg
programmers working in the single-programming and multi-programming modes. These tabs are
identical for the ChipProg-G4 gang programmer and for the -48, ChipProg-40 and ChipProg-ISP
programmers when they are configured to work in the multi-programming mode. See:
The Program Manager tab
Since the only AutoProgramming is available in the multi-programming mode this tab serves for manual
AutoProgramming initiation, displaying the site statistics ChipProgUSB program.
? 2010 Phyton, Inc. Microsystems and Development Tools
